| D-SUB 9P(HD 15P) 弯头连接线 | |
| 连接器(connector): | D-SUB 9pin female solder,housing color:black |
| D-SUB 9pin female solder,housing color:black | |
| 电缆(wire): |
UL2464 24AWG*4P+24AWG*1C+AED PVC jacket color:see part number OD=6.5mm |
| 颜色(color): | Black,Gray |
| 长度(length): | 1M,3M…30M.(Customizable) |
| 电气特性(Electrical characteristics): | a) Contact currect rating: 5 Amp |
| b) Dielectric withstanding voltage:500V AC | |
| c) Insulation resistance: 1MΩ/Min | |
| d) Contact resistance: 5Ω/Max | |
| e) Operaion temperature: -25℃～+85℃ | |
| 产品特点(productfeatures): |
●优质纯铜双绞电缆 Pure copper double stranded cable |
|
●双层屏蔽(铜编织) Double shield (braided copper) |
|
|
●成型外模更稳定 Molding outside more stable |
|
| 产品应用(application): |
该产品主要用于工业设备,运动控制卡等信号传输. Industrial equipment, motion control card |
| 环保标准(Environmental standards): |
Rohs compliant |
